Rugged HD IP 1080P Explosion Proof Camera for Fuel Transport Trucks

FOB Reference Price:Get Latest Price
  • 1 - 49 Pieces
    $115.00
  • 50 - 199 Pieces
    $109.00
  • 200 - 7999 Pieces
    $106.00
  • >=8000 Pieces
    $87.20
Shipping:
Support Sea freight
Samples:
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SOWZE
Model Number:
SW-MI2135XE
Certification:
CE
Warranty:
1 Years
Housing:
304L stainless steel
IR Range:
Up to 20m
Image Sensor::
1/2.9" SONY low illumination CMOS
Lens:
4mm, 6mm, 8mm Lens for choice
Resolution:
HD IP 1080P/2MP
Min. Illumination:
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Day& Night::
ICR (Auto/Schedule/Alarm Trigger)
Dimensions:
106 x 85 x119 mm
Power Supply:
DC12V
Product name:
Explosion Proof Camera
Supply Ability
Supply Ability:
9000 Piece/Pieces per Month Explosion Proof Camera
Packaging & Delivery
Packaging Details
Explosion Proof Camera:
Retail box for each camera inside, and carton outside
Port
Shenzhen
Lead Time :
1-5 working days after payment received
Video Description

Rugged HD IP 1080P Explosion Proof Camera for Fuel Transport Trucks



Sowze Anti-explostion camera line delivers reliable process, safety, and security monitoring in harsh, hazardous and corrosive environments. These rugged cameras are certified for use in areas where ignitable concentrations of gases or liquids exist.



Features:

Ingress Protection: IP66

Integrate explosion-proof camera and infrared lamp with intelligent design

304L stainless steel, polished finish appearance, corrosion-proof treated internal parts

Silicone O-ring seals



Parameters:

ModelSW-MI2135XE
General
Marking: Ex II2G db ⅡC T6;
Ex II2D tb  IIIC (85°C) Db
Ingress Protection:  IP66
Operating Conditions:-30 °C ~ 70 °C (-22 °F ~ 158 °F)
 Humidity 95% or less (non-condensing)
Material:304L stainless steel
Power Supply:DC12V
IR Range:Up to 20m
Dimensions:Camera: 106 × 85 × 119 mm
Unit weight:1.8 kg
Electrical Connectivity: Composite Cable
Interface spec:G-1/2''
Method of installation:Ceiling type & wall mounting
Camera
Image Sensor:1/2.9" SONY low illumination CMOS
Signal System:PAL/NTSC
Min. Illumination:0.01Lux @(F1.2,AGC ON) ,0 Lux with IR on
Shutter time:1/50(1/60)s to 1/10,000s
Lens:4mm/6mm/8mm optional
Day& Night:ICR (Auto/Schedule/Alarm Trigger)
Compression Standard
Video Compression:H.264,support dual stream,AVI;0.1M~6Mpbs variable;1~30f/s variable
H.264 code profile:Baseline profile/main profile/high profile
Video bit rate:32Kbps~16Mbps
Max. Image Resolution:1920 x 1080
Frame Rate:50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Image Settings:Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
Day/Night Switch:Auto/Schedule/Triggered by Alarm In
Network
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP
System Compatibility:ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
